GE IS220UCSAH1A Mark VIe Controller Module

IS220UCSAH1A Mark VIe Controller Module



The IS220UCSAH1A Module contains a 667 MHz Power QUICC II





Pro Freescale processor. Two 10/100BaseTX Ethernet ports





provide connectivity to the UDH, and three additional 10/100Base





TX Ethernet ports provide connectivity to the IONets.







LEDs



The UCSA module has the following LEDs:



• Link displays solid green if the Ethernet PHY on the UCSA has established a link with an Ethernet switch port.



• Act indicates packet traffic on an Ethernet interface. This LED may blink if the traffic is low, but is solid green in most systems.



• Power displays solid Green when the internal 5 V supply is up and regulating. The UCSA converts the incoming 28 V dc to 5 V dc. All other internal power planes are derived from the 5 V.



• Boot displays solid red or blinking red during the boot process. The boot blink codes are described below.





− Online displays solid green when the controller is online and running application code.



− Flash blinks amber when any flash device is being accessed.



− Dc displays solid green when the controller is the designated controller.



− Diag displays solid red when the controller has a diagnostic available. The diagnostic can be viewed and cleared using the ToolboxST application.



− On displays solid green when the USB is active.





Technical Specifications

Manufacturer	GE
Part Number	IS220UCSAH1A
Ordering Information	IS220UCSAH1A
Product Catalog	Mark VIe
Description	Controller Module
Voltage	28 Vdc
Frequency	1 Hz
Dimensions	20 cm x 16 cm x 4 cm
Weight	1 kg

Warranty :    We offer one year warranty for all original new product.

Delivery   :     We will choose the DHL/FEDEX/TNT/UPS.

Payment   :    100% advance payment bank wire transfer.

Returns   :    Quality problems can be replaced within 15 working days from the date of receipt of the product,  repair services can be provided within 1 year.

Please contact us to get the product manual.

  One year warranty on sold items

   Available for dispatch immediately

Global supplier of quality automation and control components

Questions? Call +86 18050017653  or Email sales4@nseauto.com
