The TC-FPCXX2 is a non-redundant AC-input power supply module for Honeywell Experion LS Series-A Chassis I/O systems.
Brand :
HoneywellPart number :
TC-FPCXX2Description :
Power Supply ModuleOrigin :
USACondition :
NewDimension :
11.2 cm x 14.5 cm x 14.0 cmWeight :
1.1 kgPayment :
Bank Transfer
Honeywell TC-FPCXX2 Power Supply Module
Description
Input Voltage Range：85-132 VAC or 170-265 VAC (selectable)
Input Power²：150 VA, 92 W
Maximum Inrush Current：15 A
Frequency Range：47-63 Hz
Total power output maximum, watts：70W@60 C
Backplane Output Current, Maximum³：
Wiring：#14 AWG (1.4 mm)
Location：Left side of chassis (does not consume a slot)
Feature
1. Input may drop to 16 V for a maximum of 2 minutes each hour for motor starting.
2. Note earlier models were rated as follows: TC-FPCXX1 -- 55 W @ 60 C; 70 W @ 45 C and TC-FPDXX1 -- 50W@60 C;70W@40 C.
3. The combination of a output power (5 V backplane, 24 V backplane, 3.3 V backplane and 1.2 V backplane) cannot exceed 70 W.
4. This fuse is intended to guard against fire hazard due to short circuit conditions and may not protect the power supply from d ge under overload conditions
Technical Specifications
| Manufacturer | Honeywell |
| Part Number | TC-FPCXX2 |
| Ordering Information | TC-FPCXX2 |
| Product Catalog | Honeywell C200 |
| Description | Power Supply Module |
| Voltage | 85-132 VAC or 170-265 VAC (selectable) |
| Current | 15 A |
| Dimensions | 11.2 cm x 14.5 cm x 14.0 cm |
| Weight | 1.1 kg |
