VMU100 204-100-000-013 2/1/0/0/1 Vibration Monitor

VMU100 204-100-000-013 2/1/0/0/1 Vibration Monitor

Description

VMU100 204-100-000-013 is a fully programmable, single-channel, microprocessor-based acceleration monitor specifically designed for vibration monitoring of industrial rotating machinery. It features a rugged enclosure with IP65 protection level and can operate stably in harsh industrial environments such as factories. The input processing module is compatible with all constant current-powered acceleration sensors (such as the CE680 series), and supports a maximum 500-meter long-distance transmission between the sensor and the monitor.

This monitor is equipped with an internal self-check circuit, relay output and BNC analysis output interface, which can be directly connected to data acquisition units or spectrum analyzers. It also supports multiple AC/DC power supply options, enabling flexible adaptation to the power supply requirements of different industrial sites, providing reliable vibration data support for the condition monitoring and fault warning of rotating equipment such as motors, pumps, and gearboxes.

Features

• Product Type: Single-channel programmable acceleration monitor
• Core Function: Vibration signal acquisition, processing, condition monitoring and fault warning
• Protection Grade: IP65, suitable for harsh industrial environments
• Sensor Compatibility: Supports all constant current-powered acceleration sensors, with a maximum transmission distance of 500 meters
• Interface Configuration: Self-check circuit, relay output, BNC analysis output
• Power Supply Options: Multiple AC/DC power supplies, suitable for different on-site requirements
• Application Scenarios: Vibration monitoring for industrial rotating machinery (motors, pumps, gearboxes, etc.)

Technical Specifications
