Woodward 5464-331 Kernel Power Supply Module

Woodward 5464-331 Kernel Power Supply Module

Functional Description

Each Real Time SIO Module contains the circuitry for three RS-485 ports. Each port is designed to communicate with EM or GS/LQ Digital Actuator Drivers. For each port, one driver is allowed for every 5 ms. Each driver is identified by its address switches, which must match the driver number in the GAP application program. The RS-485 communications to the Universal Digital Drivers can be used for monitoring or control purposes.

Features

•  5 ms update rate for critical parameters, with one driver per port
•  Digital Actuator Driver interface
•  Each RS-485 port may run in a different rate group
•  Communication fault detection for each driver, drivers with comm faults are disabled
•  Monitoring of driver parameters remotely
•  Configuration of driver parameters remotely
•  Allows a fast and very accurate position command (16 bits, no noise) for the drivers

Installation

The modules slide into card guides in the control’s chassis and plug into the motherboard. The modules are held in place by two screws, one at the top and one at the bottom of the front panel. Also at the top and bottom of the module are two handles which, when toggled (pushed outward), move the modules out just far enough for the boards to disengage the motherboard connectors.

Technical Specifications
