TRICONEX RO3451 Relay Output Module

TRICONEX RO3451 Relay Output Module

Description

RO3451 is a dedicated relay output module for Triconex Tricon fail-safe safety control system. It is used in conjunction with the matching output base plate. Through the relay contacts, it outputs switch control signals to drive on-site solenoid valves, audible and visual alarms, safety shut-off valves and other actuators. It is mainly used in SIS safety interlock action control in petrochemical, power plants and natural gas pipelines.

The module is equipped with a three-redundant TMR safety architecture. It has independent isolated relay channels, output signals with fault self-checking function, and can monitor contact abnormalities in real time. The standardized rack installation design is compatible with standard system cabinets. The relay contacts are isolated strongly, can resist on-site electromagnetic interference, and can stably output critical interlock instructions such as safety shutdown and alarms.

Features

The dedicated relay output module of the Tricon system, matching the corresponding output base plate

Isolated relay channels, outputting switch quantity control signals to drive on-site equipment

TMR (Three Redundancy Fault-Tolerant) architecture, compliant with industrial functional safety standards

Real-time fault detection of channels, promptly reporting abnormal contact faults

Used for interlock control scenarios such as safety shutdown, alarm, valve drive, etc.

Standard rack structure, compatible with all Tricon series hardware

Electrical isolation of contacts, anti-interference, suitable for harsh working conditions in chemical and power industries

Technical Specifications
