For the best price on RFO810, please contact us and we will get back to you within 24 hours. Topteng Technology understands the importance of your needs and is committed to minimizing lead times.
Brand :
ABBPart number :
RFO810Description :
Fiber Optic Repeater ModuleOrigin :
IndiaCondition :
NewDimension :
124 mm x 186 mm x 127 mmWeight :
0.61 kgPayment :
Bank Transfer
Fiber Optic Repeater
The ABB RFO810 optical repeater module is part of the fiber-optic
based communication link. It can be used with both HR Series and SD
Series controllers. It transparently extends communication to I/O
devices on the HN800 bus up to 3 km for remote applications.It
can also be used to extend peer-to-peer communication between
HPC800 controllers (CW800) up to 3 km.
|
Power requirements
|
24 VDC ± 10% at 90 mA; 2.16 W typical
|
|
Communication rate
|
4 Mbps on HN800 and CW800
|
|
Bus redundancy
|
Yes
|
|
Devices
|
Up to 64 HN800 devices on each electrical HN800 bus
Up to 30 single HPC800 controllers or 15 redundant pairs
of HPC800 controllers on electrical CW800 bus on each
side of the optical link
|
|
Fiber optic cable
|
Fiber size: 62.5/125 μm
Fiber attenuation: -3.5 dB/km
Index: Graded
Wavelength: 840 nm
Bandwidth: 160 MHz/km
Connector type: 10 ST style with right angle strain relief,
40 mm (1.5 in.) bend radius
Transmission mode: Multimode
|
|
Ambient temperature
|
0 °C to 55 °C (32 °F to 131 °F). Tested according to
IEC/EN 60068-2-1, IEC/EN 60068-2-2, IEC/EN 60068-2-14
|
|
Dimensions (with base)
|
124 mm width, 186 mm height, 127 mm depth
(4.88 in. width, 7.32 in. height, 5 in. depth)
|
|
Weight |
0.61 kg |
Warranty : We offer one year warranty for all original new product.
Delivery : We will choose the DHL/FEDEX/TNT/UPS.
Payment : 100% advance payment bank wire transfer.
Returns : Quality problems can be replaced within 15 working days from the date of receipt of the product, repair services can be provided within 1 year.
Please contact us to get the product manual.
